General view of machine installation and working appearance
Release time:
2014-02-28 14:42
Source:
The above figure confirms the length of the location, taking into consideration the placement of raw materials (reeds and reed boards), and the workspace is set up as follows: Note: 1: The foundation of the mechanical installation location should remain balanced. (Figure 1) 2: The pit entrance is located under the distribution box in front of the reed board machine for convenient operation. (Figure 2) 3: Per meter 4: The feed hopper and reed board machine are placed centrally aligned.
The above location is confirmed in terms of length, considering the placement of raw materials (reeds and reed boards), and the following scheme is set for the workplace: Note: 1: The foundation of the machine installation location should be kept balanced. (Figure 1) 2: The pit entrance is set under the distribution box in front of the reed board machine for convenient operation. (Figure 2) 3: Per meter 4: The center of the feeding grass box and the reed board machine are aligned. 5: Power supply (380V, three-phase four-wire) 6: A leakage protector must be equipped in front of the input power supply, and the power lines must be arranged by professionals.
